| Multi-platform Solutions / Down Blowing |
|
Igloo DHP4-09 |
|
|
|
| |
|
| |
| Features |
 Four high heat capacity heat-pipes are used.
Heat-pipes contact CPU directly
PWM fan is used
Easy to install |
| |
| |
| Specifications |
|
| Model Name |
Igloo DHP4-09 |
| Socket Type |
Intel LGA1700 / 1200 /115X (up to 190W)
AMD AM4/AM5 (up to 170W) |
| Dimension (mm) |
92×106×79 |
| Weight (gram) |
295 |
| Heatsink Material |
ALUMINUM + COPPER |
| Fan |
Bearing Type |
Hydro-Dynamic |
| Rated Voltage |
DC12V |
| Dimension (mm) |
92×92×25 |
| MTBF (hour/25°C) |
40,000 |
| Speed(RPM) |
PWM 900~2700 (4 pin, controllable) |
| Airflow (CFM) |
50 |
| Noise (dBA) |
35 |
| Safety |
CE |
| Cable length(mm) |
200+/-10 |
| Interface Material |
High Efficiency Thermal Compound |
|
| |
| |
| |
| |
| |
|
|
|
| |
 |
| |
| |
|
|
