| Multi-platform Solutions / Side Blowing |
|
Igloo SHP6-12 |
|
|
|
| |
|
| |
| Features |
 Six high heat capacity heat-pipes are used.
Heat-pipes contact CPU directly.
PWM fan is used.
Easy to install. |
| |
| |
| Specifications |
|
| Model Name |
Igloo SHP6-12 |
| Socket Type |
Intel LGA1700 / 1200 /115X (up to 190W)
AMD AM4/AM5 (up to 170W+) |
| Dimension (mm) |
120×67×155 |
| Weight (gram) |
455 |
| Heatsink Material |
ALUMINUM + COPPER |
| Fan |
Bearing Type |
Hydro-Dynamic |
| Rated Voltage |
DC12V |
| Dimension (mm) |
120×120×25 |
| MTBF (hour/25°C) |
40,000 |
| Speed(RPM) |
PWM 900~2500 (4 pin, controllable) |
| Airflow (CFM) |
105 |
| Noise (dBA) |
43 |
| Safety |
CE |
| Cable length(mm) |
300 ±10 |
| Interface Material |
High Efficiency Thermal Compound |
|
| |
| |
| |
| |
| |
|
|
|
| |
 |
| |
| |
|
|
