| Intel LGA 1150/1151/1155/1156/1200 |
|
Igloo i620 Series |
 |
|
|
| |
|
| |
Highlighted features
 High Quality Aluminum Alloy
High Fin Density
PWM Version: Fan speed increase with the increase of CPU loading
Constant Fan Speed Version: The best price-performance
Weight / noise performance
Easy to install |
| |
| Specifications |
|
| Model |
Igloo i620 Light (E)/(B) |
Igloo i620 (E)/(B) |
Igloo i620 PWM (E)/(B) |
| Socket Type |
Intel LGA 1150/1151/1155/1156/1200 |
| CPU Compatibility |
Intel® Core™ i3, i5, i7, i9 (up to 65W) |
| Dimension (mm) |
Ø 95×29(H) |
| Weight (grams) |
200 |
| Fan |
Bearing Type |
Entering Bearing / Two Ball Bearing |
| Rated Voltage |
DC 12 V |
| Dimension (mm) |
80 x 80 x 10 |
| MTBF (hour/25°C) |
30,000 hours / 50,000 hours |
| Speed(RPM) |
2600 |
3200 |
PWM 800
~3600 |
| Airflow (CFM) |
17.6 |
24.6 |
Max. 27.5 |
| Noise (dBA) |
25.8 |
28.9 |
34.2 (max.) |
| Safety |
UL, CE |
| Interface Material |
High Efficiency Thermal Compound |
|
| |
| |
| |
| |
|
|
|
| |
 |
| |
| |
|
|
